T-16DT
Call for Pricing
Price
|
Capacity (pounds) |
16,000 |
|
GVWR (pounds) |
20,600 |
|
GAWR (pounds) |
14,000 |
|
Avg. Weight (pounds) |
4,200 |
|
Load Width (in) |
80″ |
|
Deck Height (in) unloaded |
21.5″ |
|
Std. Hitch Size (in) |
3″ |
|
Tongue/Gooseneck Length (ft) |
5′-0″ |
|
Safety Chain |
3/8 Gr. 70 |
|
Parking Jack |
12K |
|
Bolted-on Parking Jack |
Y |
|
Main Beam |
6″ I-Beam |
|
Deck Type |
Drop-Deck Tilt |
|
Deck Safety Lip |
Y |
|
Deck Material |
White Oak |
|
Added Stationary Deck |
O |
|
Ramp Size (ft x in) |
N/A |
|
Load Angle (degrees) |
11 |
|
Dump Angle |
N/A |
|
Beavertail |
N/A |
|
Ramp Hold-Up |
N/A |
|
Ramp Spring Assist (off deck) |
N/A |
|
Ramp Spring Assist (off ground) |
N/A |
|
Tie Downs |
D-rings |
|
No. of Tie Downs |
8 |
|
Axle Capacity |
8K |
|
No. of Axles |
2 |
|
Axle Spread (in) |
34″ |
|
Hubs |
EZ-Lube |
|
Brake Size |
12.25″ x 3.38″ |
|
Electric Brakes |
Std. |
|
Air Brakes |
N/A |
|
Wheels (size) |
17.5″ |
|
Wheel Bolt Pattern |
8-bolt |
|
Tires |
215/75Rx17.5 |
|
Tire Load Rating |
H |
|
Lights |
LED |
|
Full Warranty |
1 Year |
|
Frame Warranty |
10 Year |
